Basic parameters
|
|
Hardware parameters |
data interface |
RS232/RS485_1 |
baud rate：600bps - 115200bps |
| RS232/RS485_2 |
baud rate：600bps - 115200bps |
|
| RS485_3 |
baud rate：600bps - 115200bps |
|
| RS485_4 |
baud rate：600bps - 115200bps |
|
| DI |
4 |
|
| DO |
4 |
|
| WIFI |
Support(Select according to customer needs) |
|
| GPSSupport |
(Select according to customer needs) |
|
| LAN Port |
10/100M Adaptive Ethernet Port, meeting IEEE802.3-2005 standard |
| WAN Port |
10/100M Adaptive Ethernet Port, meeting IEEE802.3-2005 standard |
|
| Networking method |
Networking mode supports mobile/unicom/telecommunication 5G/4G, union/3G |
|
| working voltage |
DC 9~48V, anti reverse connection, anti surge, overcurrent protection |
|
| Maximum power consumption |
2.6w |
|
| Basic power consumption |
1.68W |
|
| working temperature |
-40°℃~65°℃ |
|
| Storage temperature |
-40°C~85°℃ |
|
| working humidity |
5%~85%(No Frost) |
|
| EMC characteristics |
static electricity:EN61000-4-2,level 3 |
|
| Radiated electric field: EN61000-4-3,level 3 |
|
| Pulsed electric field:EN61000-4-4,level 3 |
|
| surge:EN61000-4-5, level 3 |
|
| Conducted Harassment:EN61000-4-6,level 3 |
|
| Power Frequency Magnetic Field:EN61000-4-8,Horizontal/Vertical400A/m (>level 3) |
|
| Oscillating Wave Resistance:EN61000-4-12, level 3 |
|
| button |
Pinhole button, long press for 3 seconds to restore factory default parameters |
|
| SM card connector |
1.8V/3V,Drawer-type card connector |
|
| indicators |
With PWR, LINK, RSSl, 2G, 4G, WAN, 232, 485 and LAN indicators |
|
| SD card |
Supports large data storage |
|
| cooling method |
Natural wind cooling |
|
software function |
breakpoint transmission |
Support |
|
| Data distribution |
Supports MQTT and HJ-212 protocols* |
|
| Power failure alarm |
Support |
|
| Telephone alarm |
Support |
|
| Communication protocol |
Serial port |
Siemens，Mitsubishi FX Series，Schneider，Delta DVP Series，XINJE，FATEK etc |
|
| Network interface |
Siemens，Mitsubishi Q Series，Fins_Ethernet，Delta DVP Series，FATEK etc |
|
| Frequency division upload |
Real time upload, change upload, and scheduled upload |
|
| Data Report |
Periodic Storage, Conditional Storage, Change Storage |
|
| Remote Upgrade |
Support for remote firmware upgrade |
|
| PLC Remote Debugging |
Support remote PLC debugging, PLC program download |
|
| Edge calculation |
Support for script development* |
|
| Available cloud platform services |
|
| cloud platform services |
Cloud Configuration |
Support |
|
| Data storage |
Support |
|
| Mobile terminal monitoring |
Support |
|
| organizational structure |
Support |
|
| Role permissions |
Support |
|
| SMS alarm |
Support |
|
| Internet of Things card management |
Support |
|
| Style customization |
Support |
|
| openAPl |
Support* |
|
| Wireless parameter |
|
Wireless parameter |
frequency range |
Conduction Transmitted Power |
Conduction Reception Sensitivity |
|
| WCDMA B1 |
24dBm +1/-3dBm |
<-109dBm |
|
| WCDMA B2 |
24dBm +1/-3dBm |
<-108dBm |
|
| WCDMA B5 |
24dBm +1/-3dBm |
<-110dBm |
|
| WCDMA B8 |
24dBm +1/-3dBm |
<-110dBm |
|
| FDD-LTE B1 |
24dBm +1/-3dBm |
<-97dBm |
|
| FDD-LTE B3 |
24dBm +1/-3dBm |
<-97dBm |
|
| FDD-LTE B5 |
24dBm +1/-3dBm |
<-95dBm |
|
| FDD-LTE B7 |
24dBm +1/-3dBm |
<-97dBm |
|
| FDD-LTE B8 |
24dBm +1/-3dBm |
<-98dBm |
|
| FDD-LTE B34 |
24dBm +1/-3dBm |
<-97dBm |
|
| NR n1 |
24dBm +1/-3dBm |
TBD |
|
| NR n28 |
24dBm +1/-3dBm |
TBD |
|
| NR n41 |
24dBm +1/-3dBm |
TBD |
|
| NR n77 |
24dBm +1/-3dBm |
TBD |
|
| NR n78 |
24dBm +1/-3dBm |
TBD |
|
| NR n79 |
24dBm +1/-3dBm |
TBD |
|
